Lx.5 - LC Fiber Optic Patch Cord Cable Simplex Single Mode 2.0mm High RL , Low IL

Name: Lx5 LC Fiber Optic Patch Cord Cable Simplex Single Mode 20mm High RL Low IL
Brand: YINGDA
Price: 0.36 USD

China Lx.5 - LC Fiber Optic Patch Cord Cable Simplex Single Mode 2.0mm High RL , Low IL factory

Brand Name : YINGDA

Model Number : FPC-LXLC-SSX-20-02

Certification : ISO SGS ROHS

Place of Origin : china

MOQ : 500 pcs

Price : 0.36USD-30USD

Payment Terms : Western Union, T/T

Supply Ability : 60,000 pcs per month

Delivery Time : 7days after payment

Packaging Details : 1 pc/ box, 200pcs / carton box

connector : LX.5, LC

fiber count : SIMPLEX

insertion loss : <0.3dB

Cable length : 2meter

Cable diameter : 2.0mm

fiber type : singlemode SM 9/125um

package : 1pc / plastic bag

cable color : yellow

return loss : >65dB UPC

connector house color : blue

product name : fiber cable,fiber optic patch cables,fiber optics patch cords,fiber optic jumpers,fiber optic jumper cables,fiber optik patch cord

Contact Now

Lx.5 - LC Fiber Optic Patch Cord Cable Simplex Single Mode 2.0mm LSZH 3D Test Report

Features

PC/UPC/APC end face
High RL,Low IL
High stability and reliability
0.9,2.0,3.0mm cable diameter optional

Technical parameters

Conforms to IEC-61754-20 standard
Conforms to Telcordia-GR-326-CORE standard
Conforms to ROHS standard
Conforms to EN186270 standard

Specification

Fiber mode	SM			MM
Connector type	Lx.5-LC
diameter	0.9mm,2.0mm,3.0mm
End face	PC	UPC	APC	PC
IL	≤ 0.30	≤ 0.30	≤ 0.30	≤ 0.30
RL	≥ 45	≥ 50	≥ 60	≥ 35
Interchangeability	0.2dB
Repeat-ability	0.2dB
Working temperature	-40~+75℃
Storage temperature	-40~+85℃
Working wavelength	1310/1550nm			850nm

Application

Fiber Optic Communication System
Fiber Optic Test instruments
CATV network
LAN/LOCAL network

Lx.5 - LC Fiber Optic Patch Cord Cable Simplex Single Mode 2.0mm High RL , Low IL
